316 Stainless Steel Angle/Section
316 stainless steel U-channel is an austenitic chromium-nickel stainless steel reinforced with molybdenum, which enhances its resistance to corrosion, especially in chloride environments. This U-channel is known for superior corrosion resistance, making it ideal for marine and chemical applications. It offers excellent weldability and formability, and is commonly used in environments where both strength and resistance to corrosion are required, such as in architectural trims, construction frameworks, and marine structures. 316 stainless steel U-channel is also used in food processing, pharmaceutical equipment, and medical device manufacturing due to its excellent durability and resistance to a wide range of chemicals and acids.
Description
| Name | Stainless Steel Angle/Section | |||
| Technique | CR/HR | |||
| Standard | AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc. | |||
| Steel Grade | 201;301;304;310S;316;321;430;2205;2507;904,etc. | |||
| Tolerance | +/-0.01-1.0% | |||
| Length | Customization | |||
| Thickness | 0.4-30mm / Customized | |||
| Service | OEM, Customized Processing Service | |||
| Processing Type | Cutting,Bending,Machining,Fabrication | |||
CHEMICAL COMPOSITION:
| Grade | C | Si | Mn | p | S | Ni | Cr | Mo | N |
| 201 | ≤0 .15 | ≤0.8 | ≤1.0 | ≤0.04 | ≤ 0.03 | 17.5-18.5 | 19.5-20.5 | 6.0-6.5 | 0.18-0.20 |
| 904L | ≤0 .02 | ≤1.0 | ≤2.0 | ≤0.045 | ≤0.035 | 23.0-28.0 | 19.0-23.0 | 4.0-5.0 | ≤0.1 |
| 654SMO | ≤0 .02 | ≤0 .5 | 2.0-4.0 | ≤0.03 | ≤0.005 | 21.0-23.0 | 24.0-25.0 | 7.0-8.0 | 0.45-0.55 |
| 253MA | 0.05-0.1 | 1.4-2.0 | – | ≤0.045 | ≤ 0.03 | 10.0-12.0 | 20.0-22.0 | – | 0.14-0.20 |
| AL-6XN | ≤0 .02 | ≤1.0 | ≤2.0 | ≤0.04 | ≤ 0.01 | 23.5-25.5 | 20.0-22.0 | 6.0-7.0 | 0.18-0.25 |
| 304 | ≤0 .08 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 8.0-10.5 | 18.0-20.0 | – | – |
| 304L | ≤0.03 | ≤1.0 | ≤2.0 | ≤0.035 | ≤ 0.03 | 9.0-13.0 | 18.0-20.0 | – | – |
| 309S | ≤0.08 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 12.0-15.0 | 22.0-24.0 | – | – |
| 310S | ≤0.08 | ≤1.5 | ≤2.0 | ≤0.035 | ≤ 0.03 | 19.0-22.0 | 24.0-26.0 | – | – |
| 316 | ≤0.08 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 10.0-14.0 | 16.0-18.0 | 2.0-3.0 | – |
| 316L | ≤0 .03 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 12.0-15.0 | 16.0 -18.0 | 2.0 -3.0 | – |
| S32760 | ≤ 0 .03 | ≤1.0 | ≤1.0 | ≤0.035 | ≤ 0.015 | 6.0-8.0 | 24.0 -26.0 | 3.0-4.0 | 0.2-0.3 |
| S32750 | ≤ 0 .03 | ≤0.8 | ≤1.2 | ≤0.035 | ≤0.02 | 6.0-8.0 | 24.0-26.0 | 2.0-3.0 | 0.24-0.32 |
